MAPS (Mitsubishi Adroit Process Suite) SCADA

MAPS SCADA | Mitsubishi Adroit Process Suite from Garland Instruments

MAPS (Mitsubishi Adroit Process Suite)

MAPS visualization solutions offer Life-cycle Engineering, SCADA, HMI, Alarm Management and intelligent reporting solutions that help customers lower their total cost of ownership.

The MAPS 4 Smart SCADA once again places MAPS at the forefront of the SCADA/HMI market. It reinforces the claim that MAPS is one of the most open, advanced and scalable SCADA platforms on the market.

MAPS version 4 has been optimised for Microsoft Windows 8, which makes it more flexible, simpler, smarter and faster offering no limitations, even for the most advanced users. The design environment is delivered through a familiar and intuitive ribbon toolbar resulting in faster engineering which leads to higher productivity and ultimately reduced cost. The Internet enabled Designer and Operator applications support hosted solutions to support the modern trend towards cloud computing.

The Technology

MAPS is a 64-bit SCADA system designed for process control, manufacturing systems and open automation applications. MAPS 4.0 is developed on the .NET platform and is compatible with various Microsoft operating systems. MAPS 4.0 has a flexible, object-oriented, client server architecture that supports any system from a stand-alone implementation to an installation spanning multiple distributed sites. Microsoft. Net 4 framework and Microsoft SQL Compact form the backbone of the MAPS software architecture. MAPS is built using Adroit’s smart-client technology offering secure web enabled user interfaces. Mitsubishi GX Works 2 is used as PLC Programming Tool.

The Architecture

MAPS is built on a client-server architecture, where the Agent Server (I/O Server) communicates with field devices and performs the Server functions of scanning, logging, alarming and value processing. The Client side (Classic and Smart User lnterfaces) provides the capability of configuring, displaying, manipulating and delivering the values in a rich, secure user interface

LINK TO MAPS SCADA WEBSITE >>
